Product Description
1.Microprocessor controlled, Pneumatically driven electronically controlled
2.10.4” TFT display screen for ventilation parameters
3.Humidifier with temperature adjustment
4.With medical air compressor, built-in backup battery up to at least 4 hours
5.Applied for Adult and Pediatric
Model: NTYK-700B NTYK-700B-1
Air Compressor: with Air Compressor without Air Compressor
Breathing Mode: A/C, IPPV, SIPPV, IMV, SIMV, PEEP, SIGH, SPONT. MANUAL
Tidal Volume: 50~1500ml
I/E Ratio: 4:1 ~ 1:4
Respiration Frequency : 1~99 bpm
IMV Frequency : 1~20 bpm
Lung compliance: ≤30 mL / kPa
Oxygen Concentration: 21%~100%
Maximum Minute ventilation: ≥18L / min
Pressure Limited: 1.0kPa~ 6.0kPa
PEEP: 0 ~ 1.0 kPa
Ptr: -1.0kPa~1.0kPa
Max .Safe Pressure: ≤6.0 kPa
Trigger Method: Pressure Trigger,Volume Trigger
