The UP Squared Pro 7000 sees dramatic improvements when compared to the boards preceding it. The first of these is that it is the worlds first industrial motherboard equipped with the Intel Core/Atom/N-Series processor platform (formerly Alder Lake-N), which offers 1.4x the CPU performance of the previous generation, alongside the benefit of supporting the Intel Distribution of OpenVINO Toolkit. In addition, the board hosts 16GB of onboard LPDDR5 4800MHz system memory, doubling the bandwidth and data transfer speed of the previous model, while also increasing overall energy-efficiency.

A first for the UP Squared Pro product line, the UP Squared Pro 7000 supports MIPI CSI cameras via an FPC port, freeing up its two 2.5GbE (Intel i226-IT) and three USB 3.2 Gen 2 ports for other peripheral devices. Developers also gain access to exceptional expansion from the dense, 4″ x 4″ (101.6mm x 101.6mm) board, with the same 40-pin GPIO header alongside M.2 E, M, and B Keys for CNVI, PCIe, and USB add-ons.

Another change likely to attract vision-intensive application developers is the boards improved display interface, which boasts HDMI 2.0b and DP 1.2 ports, along with DP 1.4a via USB Type-C to achieve three simultaneous 4K displays. Combining this with Intel UHD Graphics for 12th Generation Intel Processors makes the board an excellent base for bringing smart factory robotics and digital signage solutions to market.

The UP Squared Pro 7000 also features onboard TPM 2.0, alongside OS support for Windows 10 IoT Enterprise, Windows IoT Core, Ubuntu 22.04 LTS, and Yocto 4; in addition to its support for the Intel Distribution of OpenVINO Toolkit.

For more information about the UP Squared Pro 7000, please visit our product page or contact an AAEON representative directly.
